Earthing Switch JN15-12(7.2) 40

1.Rated voltage:12kV
2.Rated short time withstand current:40kA
3.The height above sea level shall be no more than 1000 meter;
4.Ambient air temperature: +40℃~-25℃
5.Seismic intensity: no more than 8 magnitude
6.The average relative humidity of a day should be no more than 95%, that of a month should be no more than 90%
  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service
Product Introduction

The Earthing Switch JN15-12(7.2) 40, manufactured by Shaanxi Joyelectric International Co., Ltd., stands as a pinnacle of reliability and performance in the realm of power transmission and distribution. With north of twenty years of mastery, we offer a thorough scope of items customized to meet the different requirements of our customer base around the world. The change exemplifies our obligation to greatness, giving unrivaled security and effectiveness in electrical frameworks.

Product Features

  • Robust Construction: Crafted from high-quality materials, the earth trip switch boasts a robust structure capable of withstanding varying environmental conditions.

  • Reliable Performance: Designed for optimal functionality, this earthing switch ensures seamless operation and long-term reliability in power distribution networks.

  • Enhanced Safety: Equipped with advanced safety features, including overcurrent protection and fault detection mechanisms, the JN15-12(7.2) 40 prioritizes operator safety and system integrity.

  • Easy Installation: Engineered for convenience, this earthing switch facilitates hassle-free installation and maintenance, minimizing downtime and operational disruptions.

Product Parameters

Parameter Value
Rated Voltage 12kV
Rated Current 40A
Mechanical Life 10,000 cycles
Operating Temperature -25°C to 40°C
Insulation Resistance ≥100MΩ
Contact Resistance ≤50mΩ

Function

The Earthing Switch JN15-12(7.2) 40 has multiple functions, each described below:

  • Secure Grounding: The switch ensures a reliable and safe grounding connection for electrical equipment.
  • Overvoltage Protection: It protects the equipment from voltage surges by providing a low-resistance path to ground.
  • Emergency Shutdown: The switch can be utilized to rapidly disengage the hardware from the power source in the event of crises.
  • Maintenance Isolation: It considers upkeep work to be performed on the gear while keeping it disconnected from the power supply.
  • Fault Current Diversion: When a fault occurs, the switch diverts the fault current to ground, preventing damage to the equipment.
  • Arc Suppression: It extinguishes any electric arcs that may occur during switching operations, ensuring personnel safety.
  • Capacitive Discharge: The switch can safely discharge the capacitive energy stored in the system during shutdowns or power interruptions.
  • Load Transfer: It enables the transfer of electrical loads between different power sources while maintaining proper grounding.
  • Equipment Testing: The switch facilitates equipment testing by providing a controlled grounding connection.
  • Surge Arrestor Connection: It allows for the connection of surge arrestors to protect the equipment from transient voltages.

Application

The earth trip switch finds widespread application in various sectors, including:

  • Power Distribution: Used in substations and switchyards to ensure safe disconnection and grounding of electrical circuits during maintenance and emergencies.

  • Renewable Energy: Integrated into solar and wind power systems to facilitate safe isolation of equipment for servicing and repairs.

  • Industrial Facilities: Deployed in industrial settings to protect personnel and equipment from electrical hazards during maintenance operations.

FAQ

  1. What is the primary function of an earthing switch?

    • An earthing switch is primarily used to ground electrical circuits safely, preventing the buildup of dangerous voltages during maintenance or faults.
  2. Can the JN15-12(7.2) 40 Earthing Switch withstand harsh environmental conditions?

    • Yes, the JN15-12(7.2) 40 is designed to withstand a wide range of environmental conditions, ensuring reliable performance in diverse settings.
  3. Is the installation process complex?

    • No, the JN15-12(7.2) 40 features a user-friendly design, facilitating easy installation and maintenance procedures.

Certifications

Our products, including the switch, are manufactured in accordance with stringent quality standards and hold ISO9001 certification, ensuring compliance with international quality management systems.

About Shaanxi Joyelectric International Co., Ltd.

Shaanxi Joyelectric International Co., Ltd. is a main producer and provider of influence transmission and circulation gear, with a rich inheritance crossing north of twenty years. Our obligation to advancement, quality, and consumer loyalty has impelled us to the cutting edge of the business. With a worldwide presence and an organization of believed specialists, we offer tailor-made answers for meet the developing necessities of our clients. For inquiries or to purchase the Earthing Switch JN15-12(7.2) 40, please contact us at market@joyelectric-china.com. Experience the Joyelectric advantage today!
