Earthing Switch JN15-24 31.5
2.Rated short time withstand current:31.5kA
3.The height above sea level shall be no more than 1000 meter;
4.Ambient air temperature: +40℃~ -25℃
5.Seismic intensity: no more than 8 magnitude
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Introducing the Earthing Switch JN15-24 31.5, an indispensable component in power distribution systems, designed and manufactured by Shaanxi Joyelectric International Co., Ltd. With north of twenty years of mastery in power transmission and conveyance, we present to you an item that ensures unwavering quality, productivity, and security in your electrical organizations.
Product Features:
- Robust Construction: The jw-252 earthing switch is built with high-quality materials to withstand demanding operational conditions, ensuring long-term durability.
- Enhanced Safety: Equipped with advanced safety mechanisms, including reliable interlocking systems, to prevent accidental operations and ensure personnel safety during maintenance procedures.
- High Performance: This earthing switch delivers exceptional performance with low contact resistance, facilitating efficient electrical grounding and fault isolation.
- Easy Installation: Intended for problem free establishment, with easy to use includes that smooth out the mix interaction into existing power conveyance arrangements.
- Versatile Application: Reasonable for an extensive variety of voltage levels and conditions, including substations, modern offices, and power plants, offering flexibility and versatility in different applications.
Product Parameters:
The table below outlines the basic parameters of the Earthing Switch JN15-24 31.5:
Parameter | Value |
---|---|
Rated Voltage (kV) | 24 |
Rated Current (A) | 3150 |
Mechanical Life | ≥5000 times |
Contact Resistance | ≤100μΩ |
Rated Short-time | 4s |
Withstand Current | 50kA |
Material Properties:
- Contacts: The contacts of product are constructed from a high conductivity copper alloy, ensuring minimal contact resistance and efficient electrical conduction. This allows for reliable current flow and reduces the risk of overheating or voltage drops.
- Enclosure: Made of powerful hardened steel, giving amazing security against erosion and natural variables, expanding the life expectancy of the switch.
Application:
- Power Distribution Systems: The jw-252 earthing switch is well-suited for integration into power distribution systems, where it facilitates safe operation and maintenance. Its role in providing secure grounding and fault isolation contributes to the overall resilience and stability of the electrical network, ensuring continuous and reliable power supply to consumers.
- Substations: Inside substations, the switch fills in as a basic component for guaranteeing faculty wellbeing and hardware security. By really establishing high-voltage frameworks and giving a way to blame disengagement, the switch mitigates the gamble of electrical dangers and adds to the uprightness of substation tasks, eventually supporting the strength of the more extensive power foundation.
- Industrial Facilities: In modern settings, the item assumes a key part in shielding electrical frameworks and hardware. Its capacity to give solid establishing and issue segregation abilities upgrades functional wellbeing and limits the effect of electrical aggravations, in this way supporting nonstop efficiency and limiting personal time because of electrical flaws.
- Power Plants: The item is a fundamental part in power plants, adding to the protected and proficient activity of electrical frameworks. By guaranteeing compelling establishing and issue segregation, the switch safeguards basic power age gear and staff, at last supporting the unwavering quality and execution of force plant activities.
FAQ:
- What is the rated voltage of the switch?
- The rated voltage is 24 kV.
- What is the rated current capacity?
- The rated current capacity is 3150 A.
- Is the earthing switch suitable for industrial applications?
- Yes, it is suitable for industrial facilities, substations, and power plants.
- What is the mechanical life of the switch?
- The mechanical life is ≥5000 times.
Certifications:
Our products are manufactured in accordance with ISO9001 quality management standards, ensuring adherence to strict quality control procedures throughout the production process.
At Shaanxi Joyelectric International Co., Ltd., we are focused on giving exhaustive answers for power transmission and circulation. With our broad experience, worldwide presence, and commitment to consumer loyalty, we offer altered items, one-stop support, and serious valuing. For inquiries or orders, please contact us at market@joyelectric-china.com. Choose the Earthing Switch JN15-24 31.5 for reliability, efficiency, and peace of mind in your electrical networks.
