Sf6 Upper Support for Sf6 Circuit Breaker

1.Name: Insulators
2.Material: Epoxy Resin
3.Maximum Voltage: 10kv~40.5kv
4.Usage: Insulation, Switchgear
5.Connection Method: Trough Type

Send Inquiry

Download

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Welcome to Shaanxi Joyelectric International Co., Ltd., your trusted partner in the realm of power transmission and distribution solutions. With over two decades of expertise in the field, we are proud to introduce our latest innovation: the SF6 Upper Support for SF6 Circuit Breakers.

Our SF6 Upper Support is meticulously engineered to ensure optimal performance and reliability in SF6 circuit breaker applications. It plays a crucial role in supporting the upper part of the SF6 circuit breaker, providing stability and robustness to the entire system. Crafted with precision and using high-quality materials, our upper support is designed to meet the rigorous demands of modern power systems.

Product Features:

Exceptional stability and durability
Precision-engineered for seamless integration
High-quality materials ensure reliability
Designed for easy installation and maintenance
Resistant to corrosion and environmental factors
Enhanced safety features for peace of mind

Product Parameters:

Parameter	Value
Material	Stainless Steel
Maximum Load	5000 kg
Operating Temperature	-40°C to 80°C
Weight	10 kg
Dimensions (LxWxH)	300mm x 200mm x 150mm

Application:

Our SF6 Upper Support is suitable for a wide range of SF6 circuit breaker applications across various industries including power generation, transmission, and distribution. It is designed to meet the specific requirements of medium and high voltage SF6 circuit breakers, ensuring reliable performance in critical power infrastructure.

FAQ:

What is SF6 circuit breaker? SF6 circuit breaker is a type of circuit breaker that utilizes sulfur hexafluoride gas as the insulating medium to extinguish arcs and prevent electrical faults.
Why choose SF6 Upper Support from Joyelectric? Joyelectric SF6 Upper Support offers exceptional stability, durability, and reliability backed by over 20 years of industry experience.
Is customization available? Yes, we provide customized solutions to meet the unique requirements of our clients.

Certifications:

Our SF6 Upper Support is certified with ISO9001, ensuring compliance with international quality standards and regulations.

For inquiries or to place an order, please contact us at market@joyelectric-china.com. Experience the difference with Joyelectric SF6 Upper Support for SF6 Circuit Breakers.

Shaanxi Joyelectric International Co., Ltd. is dedicated to providing high-quality products and comprehensive technical support to our valued customers worldwide. With a commitment to excellence and a passion for innovation, we strive to exceed expectations and deliver superior solutions for all your power transmission and distribution needs. Trust Joyelectric for reliable products, fast delivery, and competitive prices.
