24kV Earthing Switch for Switchgear

1.Rated voltage：24kV
2..Rated short circuit making current:80kA
3.Rated peak withstand current:80kA
4.Mechanical Life:2000 times

Send Inquiry

Download

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Shaanxi Joyelectric International Co., Ltd. is proud to introduce our cutting-edge 24kV Earthing Switch for Switchgear. With over two decades of expertise in power transmission and distribution, we bring forth a comprehensive solution tailored to meet the dynamic needs of the industry. Engineered to ensure optimal performance and safety, our earthing switch stands as a testament to our commitment to quality and innovation.

Product Features

Robust Construction: Crafted from high-quality materials, our earthing switch guarantees durability and longevity even in the most demanding environments.
Enhanced Safety: Equipped with advanced safety mechanisms, including reliable interlocking systems, to prevent accidental operations and ensure operator protection.
Seamless Integration: Designed to seamlessly integrate into existing switchgear systems, facilitating hassle-free installation and operation.
Superior Performance: Delivers consistent and reliable performance, maintaining operational efficiency under varying load conditions.
Versatile Applications: Suitable for a wide range of applications in power distribution networks, substations, and industrial facilities.

Product Parameters

Parameter	Specification
Rated Voltage	24kV
Rated Current	630A
Rated Short-Time	20kA/3s
Rated Peak Current	50kA
Mechanical Life	10,000 operations
Electrical Life	5,000 operations
Insulation Level	40.5kV
Operating Voltage	AC 220V, DC 110V/220V

Application

Our 24kV Earthing Switch for Switchgear finds extensive application in various sectors, including:

Power distribution networks
Substations
Industrial plants
Renewable energy installations
Railway electrification systems

FAQ

Q: Can the earthing switch be customized to meet specific requirements? A: Yes, we offer customized solutions tailored to your unique specifications and application needs.

Q: What certifications does the product hold? A: Our earthing switch is ISO9001 certified, ensuring compliance with international quality standards.

Q: What is the lead time for product delivery? A: We ensure fast delivery of our products, with lead times tailored to meet your project timelines.

Q: Do you provide technical support? A: Yes, we offer comprehensive technical support to assist you with installation, operation, and maintenance queries.

Certifications

Our 24kV Earthing Switch for Switchgear is certified under ISO9001, demonstrating our commitment to quality management and customer satisfaction.

About Shaanxi Joyelectric International Co., Ltd.

Shaanxi Joyelectric International Co., Ltd. is a leading manufacturer and supplier of power transmission and distribution equipment. With over 20 years of experience, we have established ourselves as a trusted partner for global clients seeking reliable and innovative solutions. Our comprehensive product range, coupled with personalized services and technical support, ensures customer satisfaction and project success. For inquiries or to purchase our 24kV Earthing Switch for Switchgear, please contact us at market@joyelectric-china.com.
