24kv VCB with Modular Mechanism and Assembly Pole
2.The performance meet C2/E2/M2 class
3.Can be matched with middle mounted switchgear and other switchgear of fixed type
4.Can be matched with switchgear of 1000mm width
5.Pole distance: 275mm
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Presenting the forefront 24kv VCB with Modular Mechanism and Assembly Pole by Shaanxi Joyelectric Worldwide Co., Ltd. Our organization invests heavily in north of twenty years of mastery in the domain of force transmission and dispersion, offering tailor made arrangements and a thorough item range. With worldwide deals and specialist organizations, we guarantee quick conveyance, unrivaled quality, and cutthroat estimating, encapsulating greatness in the electrical business.
Created with accuracy designing and best in class innovation, our 24kV VCB with Measured Component and Gathering Shaft remains as a demonstration of development and dependability in power dispersion frameworks. Our product ensures maximum safety and seamless operation in utility substations, commercial buildings, and industrial complexes.
Product Features
- Modular System: Our VCB flaunts a particular plan, working with simple establishment, upkeep, and customization, guaranteeing versatility to different applications.
- Pole of Assembly: The addition of an assembly pole reduces downtime and operational hassles by enhancing structural stability and streamlining the assembly procedure.
- High level Vacuum Innovation: Utilizing state of the art vacuum interrupter innovation guarantees unrivaled bend extinguishing execution, limiting personal time and improving functional productivity.
- Vigorous Development: Worked with excellent materials and accuracy designing, our 3150a vacuum circuit breaker ensures sturdiness, life span, and reliable execution even in testing conditions.
- Thorough Assurance: Outfitted with extensive assurance highlights, including over-burden insurance, hamper, and earth shortcoming security, guaranteeing the wellbeing of faculty and gear.
Product Parameters
| Parameter | Value |
|---|---|
| Rated Voltage | 24 kV |
| Rated Frequency | 50/60 Hz |
| Rated Current | As per requirement |
| Rated Short Circuit Breaking Current | As per requirement |
| Rated Short Circuit Making Current | As per requirement |
| Mechanical Life | 10,000 operations |
| Electrical Life | 30,000 operations |
| Operating Temperature | -25°C to +40°C |
Application
The integration of a modular mechanism and assembly pole application in a high voltage vacuum circuit breaker 24kv enhances its versatility and performance across various electrical distribution scenarios.
The modular mechanism, designed for adaptability and ease of maintenance, allows for quick and efficient replacement or upgrading of components without extensive downtime. This feature ensures operational flexibility and reduces the overall lifecycle costs of the VCB.
In conjunction with the modular mechanism, the assembly pole application plays a crucial role in ensuring the reliability and safety of the VCB. Constructed from high-quality materials such as robust insulators and conductive elements, the assembly poles provide structural integrity and electrical insulation necessary for dependable operation in demanding environments.
Applications for 24kv VCB with Modular Mechanism and Assembly Pole configurations span industrial, commercial, and utility sectors. These breakers are deployed in power generation facilities, substations, and distribution networks to protect against overcurrents, short circuits, and other electrical faults. Their ability to seamlessly integrate into existing infrastructure while offering scalability makes them a preferred choice for modern electrical systems.
Furthermore, the modular design facilitates future upgrades and adaptations to meet evolving operational requirements and regulatory standards. This adaptability ensures that the VCBs remain at the forefront of technological advancements, providing reliable and efficient performance throughout their operational lifespan.
FAQ
Q: What is the advantage of the modular mechanism? A: The modular mechanism allows for easy installation, maintenance, and customization, reducing downtime and operational costs.
Q: Is the VCB suitable for outdoor installation? A: Yes, our VCB is designed to withstand harsh environmental conditions and is suitable for both indoor and outdoor installations.
Q: Does the product come with a warranty? A: Yes, we provide a comprehensive warranty on all our products, ensuring peace of mind for our customers.
Certifications
Our products are certified to meet the highest quality standards, including ISO9001, ensuring compliance with international quality management systems.
About Shaanxi Joyelectric International Co., Ltd.
Shaanxi Joyelectric International Co., Ltd. is a leading manufacturer and supplier of electrical products, specializing in 24kv VCB with Modular Mechanism and Assembly Pole. With a commitment to excellence, we offer one-stop solutions, tailored products, and comprehensive technical support to meet the diverse needs of our global clientele. For inquiries and orders, please contact us at market@joyelectric-china.com.
